int | Start () |
| |
|
Bool | HasData () |
| |
|
int | ResetBuffers () |
| |
| | GmBufferedSensor (UInt8 iSubjectId, int iRingCount, int iDataSize, GmManagedArrayRingBuffer< uint8_t, GM_SIZE_OF_APP_DATA_QUEUE > *mainEventQueue) |
| | Constructor for derived classes, when it's OK to allocate a local buffer dynamically. More...
|
| |
| | GmBufferedSensor (UInt8 iSubjectId, int iRingCount, int iDataSize, UInt8 *puiBuffer, UInt32 uiBufferSize, GmManagedArrayRingBuffer< uint8_t, GM_SIZE_OF_APP_DATA_QUEUE > *mainEventQueue) |
| | Constructor used by most derived classes on memory-constrained systems. In this case the derived class provides a buffer, usually static, so that the buffer doesn't need to be allocated dynamically. More...
|
| |
|
int | Start () |
| |
|
int | ResetBuffers () |
| |
|
Bool | HasData () |
| |
|
int | ReadRecord (char *pcDestination, int iSize) |
| | The main interface for consumers of a sensors data to get that data. It simply copies the data in the sensor's buffer into the caller's buffer. It is up to the caller to know what to do with that data, and how to free any local memory. (This function should have been name ReadNextRecord)
|
| |
|
virtual int | DeleteNextRecord () |
| | DeleteNextRecord allows a caller to discard the next record without retrieving it. The subclasses that implement DeleteNextRecord must be able to deal with any memory that needs to be freed, or other such concerns.
|
| |
| virtual int | WriteToStorage (UInt32 ui32Topic, char *pData, UInt32 iSize, GmStorage *psStorage, UInt32 ui32FormatId)=0 |
| |
|
void | SetSensorId (int iSensorId) |
| |
|
int | GetSensorId () |
| |
|
|
static int | Initialize () |
| |
|
static int | ReadRecord (char *pcDestination, int iSize) |
| |
|
static void | ReadDataInternal (int iWhichA2D) |
| |
|
|
static int | m_static_iCurrentBuffer |
| |
|
static int | m_static_iLastBufferRead |
| |
|
static int | m_static_iLastBufferWritten |
| |
|
static IndexedAnalog32Quad | m_static_bufferCircle [COUNT_ANALOG_BUFFERS] |
| |
|
static Uint16 | m_static_count |
| |
|
static bool | m_static_boolInitialized |
| |
|
static int | m_static_iCountADCsGotten = 0 |
| |
|
|
CChildRingBuffer * | m_rbBuffer |
| | The local buffer into which the sensor or event source stores each of its events or measurements. When an item is committed to this buffer, it also adds an event (consisting of the sensor's subject ID) into the application main event queue. The full event or measurement remains here, until the application reads the subject ID out of the main queue and then asks this sensor object for the full information by calling ReadRecord.
|
| |
|
UInt8 | m_iSubjectId |
| |
|
int | m_iSensorId |
| |
The documentation for this class was generated from the following files:
- /home/kddev/dev/TivaWorkspace/TezzeretApps/Analogs.hpp
- /home/kddev/dev/TivaWorkspace/TezzeretApps/Analogs.cpp
Public Member Functions inherited from Geometrics::GmBufferedSensor
